DURAVEL H81M-SV2
introducing the Vurrion Duravel H81M-SV2 Motherboard - the perfect choice for high-performance computing! With its advanced support for M.2 NVMe SSDs, this motherboard is designed to provide you with lightning-fast data transfer speeds and lightning-quick boot times. Featuring an H81 chipset, the Vurrion Duravel H81M-SV2 is built to deliver reliable and stable performance, making it an ideal choice for both casual and professional users. With its compact Micro ATX form factor, it's also easy to fit into any desktop setup. The M.2 NVMe SSD support of the Vurrion Duravel H81M-SV2 allows for faster data transfer speeds and quicker boot times compared to traditional storage options. This means that your applications and operating system will load quickly, giving you a smooth and responsive computing experience.
Description
Tech Specs
| CPU | Intel® Socket 1150 for 4th/5th Generation |
| Chipset | Intel® B75 Express Chipset |
| Memori | 2 x DDR3 DIMM sockets supporting up to 16 GB of system memory |
| Slot Expansi | 1 x PCIe 3.0/2.0 x16 *1 1 x PCIe 2.0 x1 |
| Storage | 1 X M.2 Slot 3 X SATA 2.0 ( 3GB/s ) ports 1 X SATA 3.0 ( 6GB/s ) ports |
| Lan | Gigabit LAN Controller(s) |
| Audio | Realtek High Definition Audio |
| I/O Internal | 1 x M.2 NVME slot 4 x SATA Slot 1 x CPU Fan connector(s) (4 -pin) 1 x Chassis Fan connector(s) (4 -pin) 1 x 24-pin EATX Power connector(s) 1 x 8-pin ATX 12V Power connector(s) 1 x Front panel connector(s) 1 x Front panel audio connector(s) 1 x Internal speaker connector(s) 1 x Clear CMOS jumper(s) 1 x F-header USB 3.0 |
| I/O Port Back | 1 x DVI 1 x D-Sub 1 x HDMI 1 x LAN (RJ45) port(s) 4 x USB 2.0 2 x USB 3.0 3 x Audio jack(s) |
| Form Factor | Micro Atx architecture ( 168 X 210mm ) |
| Warranty | 2 Years warranty |
